The EIA is seriously exaggerating shale gas production in its drilling productivity report

April 21, 2014

NOTE: Images in this archived article have been removed.

“Natural gas output from US’ Marcellus edges closer to 15 Bcf/d: EIA” declared the headline in Platts that attracted my attention, since the latest data on the Marcellus shale gas play of PA and WV indicated production was less than 12 bcf/d. This headline was based on the latest issue of the EIA’s new monthly Drilling Productivity Report published April 14. Reading further, the article claimed that the Haynesville shale play “peaked at about 10 Bcf/d in 2012”, when in fact it had peaked at closer to 7 bcf/d in 2011. These errors are serious exaggerations of reality and bear further investigation, as the EIA Drilling Productivity Report is widely read and quoted in the media.

Fortunately the EIA also publishes independent production data by shale play in its Natural Gas Weekly Update. A check of production data for the Marcellus revealed that it was at 11.8 bcf/d in February and that the Haynesville had indeed peaked at 7.2 bcf/d in November 2011. These figures are also corroborated by Drillinginfo, a commercial database which is used by the EIA.

There are four shale plays in common between the two EIA reports: the Marcellus, Haynesville, Bakken, and Eagle Ford. The actual shale gas production from them, as provided in the EIA weekly update and confirmed by Drillinginfo, is illustrated in Figure 1.

Image Removed

Figure 1. Actual shale gas production from four plays from 2007 through February 2014 (data here).

The production for the same plays over this period reported in the EIA Drilling Productivity Report is illustrated in Figure 2. This amounts to revisionist history as these plays produced essentially nothing in 2007 yet are listed as producing nearly 7 bcf/d then by the EIA.

Image Removed

Figure 2. Shale gas production from the four plays in Figure 1 as reported by the EIA Drilling Productivity report (data here).

The aggregate error in reporting production from these four shale plays is illustrated in Figure 3. Production in February, 2014, is stated to be more than 7.8 bcf/d higher in the EIA Drilling Productivity Report than it actually is—an error of 38% on the upside, equivalent to more than 10 percent of the total gas production of the U.S.

Image Removed

Figure 3. Overestimation of shale gas production in the EIA Drilling Productivity Report compared to actual production for the plays and time period illustrated in figures 1 and 2.

Real production data usually lags two months behind, and the most recent months are subject to revisions. Yet the EIA’s Drilling Productivity Report confidently reports production for the current and following month to the nearest mcf (or barrel, for oil), along with aggregate depletion. Given the errors illustrated above, this is a gross distortion of the facts—and always on the upside.

Furthermore, the EIA’s decision to start putting out a report highlighting production per rig, rather than production per well, implies that rigs, not wells, are what is important. But the physical footprint on the environment is wells, not rigs, and wells determine the capital input required, plus the actual flows to markets. Presumably, given the efficiency improvements of pad drilling and other innovations allowing a rig to drill more wells per unit of time, the growth statistics per rig would make shale look ever rosier. And inflating the actual production numbers would make shale look rosier still.

The EIA is the elephant in the room when it comes to energy statistics. Its data and forecasts are widely used by analysts and the media and influence energy policy. There is no room for the significant scale of errors and distortions reported herein.

David Hughes

David Hughes is an earth scientist who has studied the energy resources of Canada for four decades, including 32 years with the Geological Survey of Canada as a scientist and research manager. He developed the National Coal Inventory to determine the availability and environmental constraints associated with Canada’s coal resources. As Team Leader for Unconventional Gas on the Canadian Gas Potential Committee, he coordinated the publication of a comprehensive assessment of Canada’s unconventional natural gas potential.

Over the past decade, Hughes has researched, published and lectured widely on global energy and sustainability issues in North America and internationally. His work with Post Carbon Institute includes: a series of papers (2011) on the challenges of natural gas being a "bridge fuel" from coal to renewables; Drill, Baby, Drill (2013), which took a far-ranging look at the prospects for various unconventional fuels in the United States; Drilling California (2013), which critically examined the U.S. Energy Information Administration’s (EIA) estimates of technically recoverable tight oil in the Monterey Shale, which the EIA claimed constituted two-thirds of U.S. tight oil (the EIA subsequently wrote down its resource estimate for the Monterey by 96%); Drilling Deeper (2014), which challenged the U.S. Department of Energy’s expectation of long-term domestic oil and natural gas abundance with an in depth assessment of all drilling and production data from the major shale plays through mid-2014; and Shale Gas Reality Check (2015) and Tight Oil Reality Check (2015), updates to Drilling Deeper. Separately from Post Carbon, Hughes authored BC LNG: A Reality Check in 2014 and A Clear View of BC LNG in 2015, which examined the issues surrounding a proposed massive scale-up of shale gas production in British Columbia for LNG export.

Hughes is president of Global Sustainability Research, a consultancy dedicated to research on energy and sustainability issues. He is also a board member of Physicians, Scientists & Engineers for Healthy Energy (PSE\Healthy Energy) and is a Fellow of Post Carbon Institute. Hughes contributed to Carbon Shift, an anthology edited by Thomas Homer-Dixon on the twin issues of peak energy and climate change, and his work has been featured in Nature, Canadian Business, Bloomberg, USA Today, as well as other popular press, radio, and television.


Tags: EIA projections, Shale gas
