Proponents of nuclear power always say that one of the big benefits of nuclear power is that it produces no Carbon dioxide (CO2).
This is completely untrue, as a moment’s consideration will demonstrate that fossil fuels, especially oil in the form of gasoline and diesel, are essential to every stage of the nuclear cycle, and CO2 is given off whenever these are used.
This is Ranger Uranium Mine’s Pit Number 1. All of the material removed from this hole, over-burden and ore, was moved by truck.
|These trucks run on diesel. It would be interesting to know how much diesel is used for how much ore in a year at Ranger.
If we are to increase the number of nuclear power stations, we also need to increase the number of these trucks (which obviously take a lot of fossil fuel energy to build), and the volume of diesel fuel. Currently Australia imports 26% of its diesel consumption, and this figure is rising as our oil production falls.
The tyres on these trucks are also particularly energy-intensive to make, and there is a world-wide short of these tyres.
|The ore is taken to a mill, usually nearby to keep trucking costs down. The mill crushes the rock to powder. The powder is then treated with sulphuric acid to dissolve the uranium, leaving the rock (depleted ore) behind.|
|The depleted ore is washed and neutralised using lime, and the slurry is pumped to the tailings ponds.|
|Maintaining the tailings ponds, with more diesel powered machinery.|
|Hard rock ores, such as quartz conglomerates and granites, are approximately 3 to 4 times more energy-intensive than soft rock ores (limestones and shales) to crush.|
|The dissolved uranium solution, including other metals, is then treated with amines dissolved in kerosene to selectively separate the uranium, which is then precipitated out of solution using ammonia, forming Ammonium di-uranate, or “yellowcake”.
All of these chemicals, sulphuric acid, lime, amines, kerosene and ammonia are energy-intensive to make, and the energy required is in the form of fossil fuels, that produce CO2 when used.
|In the final stage, the yellowcake is roasted at 800°C in an oil-fired furnace called a calciner. The Ammonium di-uranate is converted to 98% pure Uranium oxide (U3O8), which is a dark green powder that is packed into 44-gallon drums for shipment.|
|Drums of Uranium oxide are stacked by forklifts, while they await shipment, sometimes to the other side of the world.|
|The next stage involves dissolving the Uranium oxide in Hydrofluoric Acid and excess Fluorine gas to form Uranium hexafluoride gas :
Hydrofluoric Acid is one of the most corrosive and poisonous compounds known to man.
|The Uranium hexafluoride gas is then transported in cylinders to be enriched.|
Naturally occurring Uranium consists of three isotopes:
U-238 = 99.2745% ;
U-235 = 0.7200% ;
U-234 = 0.0055%
Despite its tiny proportion of the total by weight, U-234 produces ~49% of the radioactive emissions, due to its very short half-life.
The standard enrichment process for pressurised water reactor (PWR) fuel converts this mix to: fuel stream : U-238 = 96.4% ; U-235 = 3.6% tailings stream : U-238 = 99.7% ; U-235 = 0.3%
The centrifuges are powered by electricity, so this stage can be powered by nuclear power. However building the centrifuge cascades requires lots of fossil fuels.
|Low-enriched (3.6%) Uranium hexafluoride gas is then transported to the fuel fabrication plant.|
|The UF6 gas is converted to Uranium dioxide (UO2) powder, pressed into pellets, and baked in an oil-fired furnace to form a ceramic material. These are then loaded into a tube made of a zirconium alloy. Several of these tubes form one fuel assembly.|
Zirconium is a metallic element derived from zircon, an ore of Zirconium silicate (ZrSiO4), which is a by-product of rutile sand mining (another energy-intensive business). Naturally occuring Zirconium is always found with Hafnium, which has to be removed (with difficulty) for nuclear uses.
For every tonne of Uranium in the fuel, up to 2 tonnes of Zirconium alloy are needed.
|Fresh fuel is only mildly radioactive and can be handled without shielding. The fuel assemblies are then transported to the reactor by truck or train.
A 1000 MW(e) nuclear reactor contains about 100 – 130 tonnes of Uranium dioxide, and usually one third of that is replaced in rotation each year.
|If you ignore the vehicles that the workers use to get to work, the reactor does not produce any CO2. But it does use electricity, as well as produce it, and to the extent that electricity is largely produced by fossil fuels, this needs to be counted in the energy balance.|
|It takes a lot of steel to built a nuclear power station, and steel is made by smelting iron ore with coking coal.|
|And a nuclear power station uses lots of concrete, which is made from cement. Cement is made by crushing limestone and roasting it, using fossil fuels, to drive off Carbon dioxide. So cement is particularly CO2-intensive.|
|Spent fuel rods ‘normally’ spend six months in cooling ponds located within the reactor building, so that short-lived radio-activity can decay, making the material easier to handle. In the US and many other places, these spent fuel rods stay at the reactor a lot longer than that, while politicians argue over what to do with it next.|
|Reactor waste moved by road and rail.|
Spent fuel is kept under water until it is reprocessed. This keeps it cool and acts as a radiation shield. In the ‘once through’ process, the fuel rods are dissolved in acid, and the Plutonium is extracted, and the remainder including the Uranium becomes high-level waste. In the ‘recycling’ process, Uranium is also recovered.
|Recovered Plutonium and Mixtures of Plutonium and Uranium oxides (MOX) are sent by road back to the fuel fabrication facility to be used in new fuel rods.|
|This is not really a waste repository, ( it is the NORAD military bunker at Cheyenne Mountain ) but this is what one might look like if one was ever to be built.|
|This is a security policeman, well , it does say POLICE on his bag. I do hope everything is alright.|
|Ah, that’s more like it. How many miles per gallon do you get out of one of those ?|
|Security surveillance is needed to prevent terrorists from getting access to radio-active materials.|
|And increasingly these days, one also has to defend ones nuclear facilities against attack by an increasingly sophisticated enemy. This is the Tor-M1 – a fully integrated combat vehicle with anti-missile/anti-aircraft missiles, that the Iranians are getting from Russia to protect themselves from the peace-makers.|
As you can see, every step of the nuclear power cycle involves the expenditure of energy derived from fossil fuels, which nuclear electricity cannot replace. Thus it is untrue to say that nuclear energy is greenhouse friendly.
In the paper “Nuclear Power : the energy balance” by J.W. Storm and P. Smith (2005) download here, the authors calculate that with high quality ores, the CO2 produced by the full nuclear life cycle is about one half to one third of an equivalent sized gas-fired power station.
|For low quality ores (less than 0.02% of U3O8 per tonne of ore), the CO2 produced by the full nuclear life cycle is EQUAL TO that produced by the equivalent gas-fired power station.|
So the question is : Given that the greenhouse claims for nuclear power are false, and if the only way the nuclear industry can operate is with massive amounts of cheap fossil fuels, especially diesel derived from oil, and with oil going to be very much scarcer in the future, is this a good time to be thinking of increasing the nuclear industry ?
